Nature's Generator Elite with Cart -3600w Solar and Wind Powered

About this item

• 🌵 Dimension and Weight: 18 x 12 x 15 inches without cart; 23 × 17 × 22 inches with cart,120 lbs with cart.Please pay attention:You need to install the cart by yourself. We have placed all the installation tools in the package.
• 🌴 Battery Type: AGM Sealed Lead Acid with 100Ah (1200Wh).Recommend to recharge every 4 months.
• 🌳 Three Ways to Recharge:You can use Solar Panels,Wind Turbine and AC Power.The recharging speed depends on the the strength of the sunlight or wind.For example: It takes about 15 to 20 hours to recharge Nature's Generator if using 100 watt solar panel, and also depends on the the strength of the sunlight.
• 🌿 How to Increase Recharging Speed:The Solar/Wind Input port can handle up to 300 watt of solar power/Wind power. In other words, three 100 watt solar panels can be chained in parallel before connecting to the Solar Input port. two 150 watt wind turbines can be chained in parallel before connecting to the Wind Input port.
• 🌿 How to Increase Recharging Speed:The Solar/Wind Input port can handle up to 300 watt of solar power/Wind power. In other words, three 100 watt solar panels can be chained in parallel before connecting to the Solar Input port. two 150 watt wind turbines can be chained in parallel before connecting to the Wind Input port.

Product Description

Nature's Generator Elite

Please pay attention:

You need to install the cart by yourself.

We have placed all the installation tools in the package.

Nature's Generator Elite with Cart -3600w Solar and Wind Powered Generator in Quiet Operation with 12V DC port,2 USB ports,3 AC outlets and 120V 30amp pure sine wave AC outlet.

Back Panel

Expansion cord:

Daisy chaining fuses and daisy chain

connector. For use with Nature's Generator Power Pod Elite.

30amp AC Outlet Port:

One 120V 30amp pure sine wave AC outlet.

Get to Know Your Nature’s Generator Elite

Dimension and Weight

18 x 12 x 15 inches without cart;

23 × 17 × 22 inches with cart,

120 lbs with cart.

Front Panel

LCD Display: LCD display shows the information of the system.

LCD Display Button: Press it to light up LCD display for 30 seconds.

AC Outlets Switch: Turns on or off the front AC outlets and the 30amp AC outlet on the back of the generator.

Battery Type

AGM Sealed Lead Acid with 100Ah (1200Wh).

Recommend to recharge every 4 months.

Recommending Commodities: Nature's Generator Power Pod Elite

Dimensions and Weight

Dimensions: 18 x 12 x 15 inches;

Weight: 92Ib

Battery Capacity:1200W

Recommend to recharge every 4 months.

How to Connect to Nature's Generator Elite

There is an expansion cable in the top cover of the Nature's Generator Power Pod Elite.Connect the expansion cable to the expansion port which on the back of the Narture's Generator Elite.

LED Light

The first light will show green,which indicates 20% charge. The second light will show green, which indicates 40% charge, the third light will show green which indicates 60% charge and the fourth light will show green which indicates 80% charge and finally the fifth light will show green which indicates a 100% charge.

How to Connect Your Nature's Generator Power Pod Elite to Nature’s Generator Elite

1. Open the top cover of the Nature's Generator Power Pod Elite, locate the expansion cable, and run the expansion cable out of Nature's Generator Power Pod Elite through the opening on the back of the Nature's Generator Power Pod Elite.

2. Locate expansion port on the back of your Nature’s Generator Elite and open the rubber cover.

3. Connect the expansion cable to the expansion port. Due to the amount of voltage running between the Nature's Generator Elite and Nature's Generator Power Pod Elite, this is a very tight fit to ensure no electrical shock while connecting.

4. The Expansion (chain link) Icon will be illuminated on the display of Nature’s Generator Elite to indicate Nature's Generator Power Pod Elite is connected.
